Certified Test Pieces for X-ray Detectors
Our test pieces for X-ray detectors are beeing produced of either plastic laminate, or PMMA (Acrylic). They are EC and FDA certified and suitable for direct contact with food products.
Standard Designs
Design Dimensions Material Colours
Flexible test card
with 1 sample96 x 38 mm Plastic laminate white transparent with coloured marking
Flexible test card
with multiple samples96 x 38 mm Plastic laminate white transparent with coloured marking
Test stick50 / 75 / 100 x 10 x 5 mm PMMA (Acrylic) glass-clear with coloured writing
Test card80 x 40 x 5 mm PMMA (Acrylic) glass-clear with coloured writing
Test tag50 x 30 x 5 mm PMMA (Acrylic) glass-clear with coloured writing
Test discØ 35 / 30 / 25 / 20 / 15 x 5 mm PMMA (Acrylic) glass-clear with coloured writing
Sample Materials
Category Material Shape
Ferrous Chrome steel 1.3505 AISI 52100 Sphere
Non-Ferrous Brass CuZn35 Sphere
Stainless steel Stainless steel 1.4401 AISI 316 Sphere, wire
Stainless steel 1.4301 AISI 304 Sphere, wire
Stainless steel 1.4034 AISI 420C Sphere
Stainless steel 1.4125 AISI 440C Sphere
Aluminium Aluminium Al Sphere
Bronze Phosphor bronze PB104 Sphere
Titanium Titanium Ti Sphere
Lead Lead Pb Sphere
Copper Copper Cu Sphere, wire
Glass Soda-lime glass (SLG) Sphere
Fused quartz (Fused silica) Sphere
Borosilicate glass Sphere
Lead glass (Crystal glass) Sphere
Ceramic Ceramic (Aluminium oxide, Alumina, Al2O3) Sphere
Zirconia Zirconia (Fianit) Sphere
Plastic PA (Polyamide, Nylon) Sphere
POM (Polyoxymethylene, Acetal) Sphere
PTFE (Polytetrafluorethylene, Teflon®) Sphere
Rubber AB (Nitrile rubber) Sphere
Customized Test Pieces
On request, our test pieces are available in variant forms or dimensions according to your wishes.
Data Sheet | Enquiry
Feel free to download our test pieces’ data sheet here, or request your free individual quotation just now!
